2. Use gloves for operation. Gloves can be thickened to resist damage or thin and high-feeling
3. Select H14 high-efficiency filter and pass PAO scanning leak detection test
4. Hydrogen peroxide can achieve 10⁶-log spore killing effect on the air in the isolator and the exposed surface
5. The safe entry and exit of items can be achieved through a variety of methods, such as airlock chambers, transfer cabins with RTP systems, etc.
6. A built-in power supply can be installed in the isolator, and a compressed air connector with a valve and a cleaning water connector can also be installed for water and air intake
7. The system is equipped with a Siemens logic controller (PLC) for fully automatic control of pressure and air supply volume, and has a pressure loss alarm function
8.10-inch touch screen control/12.1-inch industrial panel PC NetSCAD system, in line with the 2010 GMP computer system verification requirements
Maximum power：≤3000W
Touch screen：12.1 inch industrial control screen
Data trackingz:support
Power supply：220V±22V,50±1Hz
The minimum resolution on humidity:0.1%
Electronic signature:support
Airflflow model in isolator cabin：Vertical unidirectional flflow
The minimum resolution on temperature：0.1℃
Online leak detection:support
Adjustment range of the pressure inside cabin：-80～+80Pa
Wind speed：0.36～0.54m/s
Online glove leak detection:support
Operating size：1790×1050×740mm
Airlock room size:600×580×740mm
Dimensions:3130×1250×2385mm
Gas source：Filtered clean compressed air or nitrogen, air source pressure 0.4 ～0.6MPa
Cabin leakage rate：The pressure holding test is carried out when the positive pressure is 80 Pa, and the overall leakage rate of the isolator cabin is less than 0.5% vol/hour
